VR10A DSP powered line array speaker:
VR10A is an extremely compact 10” two way DSP active line-array system. With an amazing SPL to size ratio, it can be used as a sound reinforcement in small to mid-size venues as well as in fixed installation.
It is made of one 10” Neodymium woofer, one 3” titanium Neodymium compression drivers with innovative horn design of wave phase philosophy; mounted ACLON customized DSP600 class D active amplifier module in cabinet;
Products are being manufactured by using highest grade materials and processed on CNC machines with latest technology. Great sound, reliability, high powerful are of paramount importance when on shows. small in size and light in weight. ACLON VR10A DSP Speaker are easy to haul around. No matter if it’s for live concert or club gigs.
Brief:
Two-way DSP class D amplifier active system
Birch plywood cabinet
Wave guide horn
Customized neodymium HF, LF
Program: 800W
Impedance: 4ohm
Net weight: 21KG
Weather-resistant, multipurpose, plug and play
Application:
Theater places expand sound systems.
Touring FOH system
Audio & video presentations sound system
Mobile or permanently live concert reinforcement
Model
VR10A
VR18SA
Drivers
2 x 1.7" HF driver
/
Woofer
1x10” LF woofer
1x18” LF subwoofer
Rated power
400W
600W
Program
800W
1200W
Peak power
1200W
1800W
Frequency range
60 - 15000 Hz
35 - 200 Hz
Impedance
4ohms
4 ohms
Coverage range (h x v)
80° or 120 ° x 10°
/
SPLmax / 1 m / peak
142 dB
139 dB
Dimensions (h x w x d)
275 x 500 x 355 mm
447*705*400mm
Finish
polyurethane coating
polyurethane coating
Color
Black or white
Black or white
Enclosure material
Birch plywood
Birch plywood
Net weight
21kg
43KG
Gross weight
24kg
46KG
