FP series are 4 channel popular amplifier, high output power amplifiers, which deliver powerful pure sonic performance.
It is a multi-functional item. Every channel have volume change output voltage independently.
It can also be bridged into bigger power 2 channels amplifier. 2U height and 13kg make it especially suitable for mobile events.
It adopts imported USA- ONSEMI (formerly Motorola) power output transistors. Reliable, durable performance can match all kinds of loudspeaker systems.
FP Series offer smooth and responsive handling with massive power output, benefit from the latest advance in SMPS technology, resulting in high power, lightweight units.
FP-Series are suitable for professional installations, theater and live sound applications.
Model FP10 FP14 Output Power(20-20kHz, 1W with 1 kHz ) 4 Channel 2 Channel 8ΩStereo Power(RMS) 1300WX4 2350WX2 4ΩStereo Power(RMS) 2200WX4 4400WX2 2ΩStereo Power(RMS) 2600WX4 6800WX2 8ΩBridged Power(RMS) 4200WX2 8800W 4ΩBridged Power(RMS) 5000WX2 14000W FrequencyResponse(+o/-0.3dB,1W/8Ω) 20 Hz - 34 kHz THD 20 Hz - 20 kHz for 1 W <0.1% Signal-to-Noise Ratio >112 dBA Damping factor >1000 Channel separation (Cross talk) at 1 kHz >70 dB Input Connectors (per channel) 3-pin XLR, electronically balanced Output Connectors (per channel) Speakon or Binding Posts 2-pole Class circuitry Class TD Tour Class Protection ACL, IGM, Auto Ramp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input Operating voltage, 230 V / 115 V normal 150-260 V50/60Hz, / 70-140 V 50/60Hz selectable Voltage Gain(dB) 23, 26, 29, 32, 35, 38, 41, 44 dB selectable Input impedance (unbalanced) 20 k Ohm (10k Ohm) Level adjustment (per ch.) Front-panel potentiometer, 31 position detente from -into 0 dB Dimensions (H×W×D) 2U: 88×483×396mm Packing dimension 180×560×500mm Net weight (kg) 13 13 Gross weight (kg) 15 15 -
• 4 Channel High Power Output
• Lightweight Switch Power Design
• High Efficiency Class TD Technology
• Stable Performance for Long Operation
• Built-in Protection System (Overheat / Short / Clip / DC)
• Suitable for Touring and Fixed Installation
-
• Concert Sound System
• Touring PA System
• Nightclub Installation
• Theater Sound Reinforcement
• Stadium Audio System
• Professional Rental System
-
Download Available:• Product Datasheet (PDF)• Technical Specification Sheet• FP Series Catalogue• OEM/ODM Information Sheet
Contact us for full technical documents. -
FP10 4 Channel Lightweight Switch Amplifier
Professional High Power Audio Amplifier
OEM/ODM Available for Global Brands
Designed for Touring and Professional PA Systems
Stable Performance with High Efficiency Output
