DK2500 series 1U class D digital amplifier will work very well installed into live concert, auditorium, and performance venues.
It can make fat profit base on high reliability, good quality. And enable you to have a competitive edge in the market.
Feature:
1. Class D circuit
2. Lightweight, 12KG
3. High reliability, work stable at 2ohm.
4. Comprehensive protection: DC protect, short circuit protect etc
5. Power supply AC: 90v-270V
Item Specification Product Model DK413 DK2500 8 OHM stereo 4X1300W 2X2500W 4 OHM stereo 4X2400W 2X4400W 2 OHM stereo 4X3000W 2X5500W 8 ohm bridge 2X4150W 1X8000W 4 ohm bridge 2X5700W 1X10000W Amplifier Topology Class D Channels 4 Channels Power Supply Active PFC Switching Power Supply AC Input Voltage 100-240V AC ±10%, 50/60Hz Operating Voltage Range 90-270V AC Gain Settings 32dB / 35dB / 38dB / 41dB Frequency Response 20Hz-20kHz (±0.5dB) Signal-to-Noise Ratio >110dB (A-weighted) THD+N <0.05% Damping Factor >5000 Maximum Output Voltage 195V Maximum Output Current 85A Cooling System Intelligent Tunnel Cooling Input Connectors Balanced XLR Output Connectors SPEAKON Operating Modes Stereo / Bridge Operating Temperature 0°C to +45°C Dimensions (W × H × D) 482*44*370mm Net Weight 12kg -
BV1300 amplifier upgraded to DK2500 amplifier
The ACLON BV1300 (DK2500) is an extreme-performance 2-channel Class D digital power amplifier engineered for continuous heavy-duty concert operation and high-volume OEM tailoring.
Massive 8000W Output Power Capability: Engineered to deliver staggering high-efficiency power to effortlessly drive large scale dual 18 inch subwoofers and massive line array networks.
High-Efficiency Class D Topography: Maximizes ultra-high power delivery while optimizing thermal dissipation and minimizing long-term electricity consumption.
Advanced Switching Power Supply SMPS: Ensures absolute voltage stability and tremendous low-end impact even under fluctuating global power grids.
Rugged 2U Chassis Design: Provides superior physical durability and optimal ventilation paths for heavy-duty touring racks and flight cases.
Comprehensive Circuit Protection: Features advanced intelligent defense against short circuits, over-current, thermal overload, DC output offset, and VHF signals to protect expensive connected speaker systems.
Premium B2B Manufacturing Quality: Built for long-term reliability and sustainable hardware execution, strictly avoiding low-cost market competition to safeguard your brand reputation.
-
Global OEM and ODM Partnerships: Fully customizable chassis front-panels, specific power tailoring, and private-label branding for European and American professional audio brands.
Professional Audio Rental and Large Touring Companies: Perfect for heavy-duty stadium touring racks, large outdoor music festivals, live concert production, and arena setups.
Professional Audio Wholesalers and Distributors: High-volume manufacturing capacity with stable quality control to support sustainable brand building.
-
Please click Contact Now or send an inquiry to our sales product managers to download the following official documentation for the BV1300 Amplifier:
ACLON BV1300 Official Technical Datasheet PDF
Professional Extreme Power Amplifier B2B Price List
ACLON OEM and ODM Hardware Customization Guide
Complete Line Array and Amplifier Matching Selection Catalog
-
Click the print option in your web browser or request the high-resolution printable PDF technical datasheet directly from our sales managers.
