VX12A 12 Inch 600W DSP Active Line Array Speaker | Professional OEM Manufacturer< back

zoom in zoom out

move up move left move right move bottom

  • Specifications
  • Feature
  • Application
  • Download
  • Print
  • VX12A 12 Inch 600W DSP Active Line Array Speaker

    The VX12A is a professional 12-inch active line array speaker featuring a built-in DSP-controlled amplifier for reliable performance and simplified system deployment. It is designed to deliver clear vocals, balanced frequency response, and high sound pressure levels for live sound applications.

    Its compact enclosure and integrated amplification make it ideal for touring productions, rental companies, churches, theaters, conference venues, and fixed installations where efficient setup and consistent performance are essential.

    ACLON offers OEM and ODM manufacturing services including private labeling, DSP customization, cabinet finishing, logo printing, packaging design, and complete professional audio solutions for international distributors and audio brands.

    Specification VX12A VX18SA
    System Type 2-Way DSP Active Full Range DSP Active 18" Subwoofer
    Transducers 1 × 12" LF + 1 × 3" HF Driver 1 × 18" Ferrite LF
    Frequency Response (-10 dB) 57 Hz – 20 kHz 31 Hz – 230 Hz
    Coverage 100° × 15° Omni
    Amplifier Power (AES) 600 W 800 W
    Peak Power 1200 W 1600 W
    Max SPL (Peak) 138 dB 139 dB
    Nominal Impedance 4 Ω 4 Ω
    Amplifier Technology Class D Class D
    DSP Control Built-in DSP with USB & RS-485 Control Built-in DSP with USB & RS-485 Control
    Audio I/O 2 × XLR (Input / Link) 2 × XLR (Input / Link)
    Dimensions (W × H × D) 595 × 375 × 350 mm 597 × 749 × 508 mm
    Net Weight 25 kg 41 kg

  • • 12-inch DSP active line array speaker
    • Built-in high-efficiency power amplifier
    • Digital signal processing for optimized performance
    • Compact enclosure with high SPL output
    • Suitable for touring and fixed installations
    • Durable plywood cabinet construction
    • OEM and ODM customization available

  • • Concert Sound Reinforcement

    • Live Touring Systems

    • Churches and Houses of Worship

    • Theaters and Auditoriums

    • Conference Venues

    • Rental Audio Companies

    • Outdoor Events

    • Professional PA Installations

  • Download Available:


    • Product Datasheet (PDF)

    • Technical Specifications

    • DSP Configuration Guide

    • OEM/ODM Product Catalogue


    Please contact us to receive the latest documentation and customization information.

  • VX12A 12 Inch 600W DSP Active Line Array Speaker


    Professional OEM/ODM Active Line Array Manufacturer


    Designed for concerts, touring productions, theaters, churches, and professional PA systems with integrated DSP control, reliable performance, and efficient deployment.
