SH41200 4×1200W Four Channel Class D Power Amplifier
The SH41200 is a professional four-channel Class D power amplifier designed for reliable sound reinforcement and installation applications. Delivering 4×1200W output power at 8 ohms, it offers excellent flexibility for driving full-range loudspeakers, stage monitors, and distributed audio systems.
Featuring a lightweight 2U rack-mount design and efficient switching power supply, the SH41200 combines portability with stable performance, making it suitable for both mobile and fixed installations.
The amplifier includes comprehensive protection functions such as DC protection, short-circuit protection, overload protection, clip limiting, and thermal protection to ensure long-term reliability.
ACLON provides OEM and ODM manufacturing services including private labeling, logo customization, front panel design, packaging solutions, and complete professional audio system support.
Model Channels 8Ω Stereo 4Ω Stereo Net weight / KG SH4600 4CH 4 × 600W 4 × 900W 11kg SH4800 4CH 4 × 800W 4 × 1250W 11kg SH41200 4CH 4 × 1200W 4 × 1800W 11kg SH41600 4CH 4 × 1600W 4 × 2000W 11kg SH600 2CH 2 × 600W 2 × 900W 6kg SH800 2CH 2 × 800W 2 × 1250W 6kg SH1200 2CH 2 × 1200W 2 × 1800W 6kg SH1600 2CH 2 × 1600W 2 × 2000W 6kg Parameter Specification mplifier Topology Class D Frequency Response 20Hz – 20kHz (±0.5dB) THD+N <0.04% Signal-to-Noise Ratio >105dB Damping Factor >1200 Channel Separation >70dB @1kHz Input Impedance 20kΩ Balanced / 10kΩ Unbalanced Input Connectors Balanced XLR Output Connectors NL4 SPEAKON Protection DC, Short Circuit, Overload, Clip Limiter, Thermal AC Voltage 110V / 230V AC Dimensions (W × H × D) 485 × 88 × 355 mm Net Weight 6kg - 11kg Related Products
• SH4800 4×800W Four Channel Amplifier
• SH41600 4×1600W Four Channel Amplifier
• FP10 Four Channel Lightweight Amplifier
• DH4-1200 Four Channel Digital Amplifier
• DK420 Four Channel DSP Amplifier -
• Four-channel Class D amplifier design• 4×1200W output power at 8 ohms• Lightweight 2U rack-mount chassis• High efficiency switching power supply• Low distortion and high damping factor• Complete protection circuitry• OEM and ODM customization available
-
• Churches and Worship Spaces
• Touring Sound Systems
• Rental Audio Companies
• Nightclubs and Entertainment Venues
• Theaters and Auditoriums
• Conference Centers
• Live Concert Reinforcement
• Professional PA Installations
-
Download Available:
• Product Datasheet (PDF)• Technical Specifications• User Manual• OEM/ODM Product Catalogue
Please contact us for the latest technical documentation and customization options. -
SH41200 4×1200W Four Channel Class D Power Amplifier
Professional OEM/ODM Amplifier Manufacturer
Designed for touring systems, churches, clubs, rental companies, and professional PA applications with reliable performance, lightweight construction, and flexible four-channel operation.
