LAM212 Dual 12 Inch Large Line Array Speaker | Professional OEM Line Array Manufacturer< back

zoom in zoom out

Specifications
Feature
Application
Download
Print

LAM212 Dual 12 Inch Large Line Array Speaker

LAM212 is a professional two-way passive large line array speaker featuring dual 12-inch low-frequency drivers and a high-frequency compression driver with waveguide technology. It is engineered to deliver powerful output, wide coverage, and consistent sound performance for demanding live events.

The enclosure is constructed from high-quality birch plywood and equipped with an integrated rigging system for fast installation and safe array deployment. It is suitable for touring productions, fixed installations, and large-scale sound reinforcement projects.

ACLON provides OEM and ODM manufacturing services, including private labeling, logo customization, cabinet finishes, packaging, and complete audio system solutions for distributors and professional audio brands worldwide.

Model	LAM208	LAM210	LAM212
LF Drivers	2 × 8" Ferrite	2 × 10" Ferrite	2 × 12" Ferrite
HF Driver	3" Neodymium Driver	3" Neodymium Driver	3" Neodymium Driver
Coverage (H × V)	90° × 8°	90° × 7°	90° × 7°
RMS Power	700W	800W	1000W
Peak SPL	138dB	142dB	145dB
Frequency Response (-3dB)	60Hz–20kHz	42Hz–20kHz	42Hz–20kHz
Dimensions (W × H × D)	610 × 340 × 280 mm	716 × 450 × 310 mm	916 × 460 × 380 mm
Weight	24kg	34kg	35kg

• Dual 12-inch two-way passive line array design

• High-output compression driver with waveguide horn

• Wide and consistent sound coverage

• Premium birch plywood enclosure

• Integrated flying and rigging system

• Designed for touring and fixed installations

• OEM and ODM customization available
• Concert Sound Reinforcement

• Live Touring Systems

• Stadiums and Arenas

• Auditoriums

• Churches and Houses of Worship

• Outdoor Events

• Rental Sound Companies

• Professional PA Installations
Download Available:

• Product Datasheet (PDF)

• Technical Specifications

• Rigging Information

• OEM/ODM Product Catalogue

Please contact us to receive the latest technical documents and customization information.
LAM212 Dual 12 Inch Large Line Array Speaker

Professional OEM/ODM Line Array Manufacturer

Designed for concerts, touring productions, stadiums, auditoriums, and professional sound reinforcement with high output, reliable performance, and efficient array deployment.
