VT 3 way high output line array speaker< back

zoom in zoom out

move up move left move right move bottom

  • Specifications
  • Feature
  • Application
  • Download
  • Print
  • VT215 is 3-way full range line array speaker

    buld in neodymium drivers

    wave guide horn

    plywood cabinet

    during rigging

    high output, high performance, great sound, suit for road show, stadium, live concert etc events.

    Products Model:    VT215    VT218S
    LF neodynium unit  2 x 15"    2 x 18"
    MF mid woofer   4x 6.5"     /
    HF neodymium drivers  2X3"    /
    Horn & Exit throat Size  2x1.5"   /
    Dispersion Angle  H90°x Vertical    /
    RMS / program  1700W/3400W   2000W/4000W
    Peak power  5100W  6000W
    Nominal MAX /Peak SPL  136dB  129dB
    Frequency Response   ( ±3dB)  60Hz - 19KHz    25Hz - 250Hz
    Crossover Frequency point  1200hz, 2.1KHz   150 Hz
    Nominal Impedance  LF/ MF: 8 ohm; HF: 16ohm   4 Ohms
    Input output Connector   2 *NL8    2 *NL4
    Dimension (mm)   1260x560x 490   1260 x560 x 700
    Net Weight   (1pcs)  65kg   87kg

  • Feature:

    1. Birch plywood 18mm, weather-resistant, scratch-resistant;

    2. Wave guide horn, dispersion AngleH90°x Vertical splay Angle

    3. Imported drivers, powerful & perfect sound.

    4. Large & multipurpose enclosed. It can hang in the air or stack on the ground.

    5. Black or white color

    6. Normal impedance: 8ohm

    7. Hardware is included, just plug and play

    8. Net weight: 46KG

  • Application:

    Theater places expand sound systems.

    Touring FOH system

    Audio & video presentations sound system

    Mobile or permanently live concert reinforcement

  • Power amplifier and line array speaker
  • amplifier and speaker
