FP10K (TD413) 4 Channel Lightweight Switch Power Amplifier
FP10K (TD413) is a professional 4-channel lightweight switch power amplifier designed for high power PA systems and touring sound reinforcement applications.
It adopts advanced switching power supply technology with high efficiency output, low heat generation, and stable long-term performance.
OEM and ODM customization is available for global audio brands, distributors, and system integrators.
- Concert Sound System
- Touring PA System
- Nightclub Installation
- Theater Sound System
- Stadium Sound Reinforcement
- Live Event Rental System
-
• 4 Channel High Power Output
• Lightweight Switch Power Design
• High Efficiency Class TD Technology
• Stable Performance for Long Operation
• Built-in Protection System (Overheat / Short / Clip / DC)
• Suitable for Touring and Fixed Installation
-
• Concert Sound System
• Touring PA System
• Nightclub Installation
• Theater Sound Reinforcement
• Stadium Audio System
• Professional Rental System
-
Download Available:• Product Datasheet (PDF)• Technical Specification Sheet• FP Series Catalogue• OEM/ODM Information Sheet
Contact us for full technical documents. -
FP10000 4 Channel Lightweight Switch Amplifier
Professional High Power Audio Amplifier
OEM/ODM Available for Global Brands
Designed for Touring and Professional PA Systems
Stable Performance with High Efficiency Output
FP series amplifiers are designed for professional audio engineers requiring stable output, high power efficiency, and reliable protection systems.
Contact us for OEM amplifier solutions and factory direct pricing.
| Model | FP10 (TD413) | FP14 (TD14) |
| Output Power(20-20kHz, 1W with 1 kHz ) | 4 Channel | 2 Channel |
| 8ΩStereo Power(RMS) | 1300WX4 | 2350WX2 |
| 4ΩStereo Power(RMS) | 2200WX4 | 4400WX2 |
| 2ΩStereo Power(RMS) | 2600WX4 | 6800WX2 |
| 8ΩBridged Power(RMS) | 4200WX2 | 8800W |
| 4ΩBridged Power(RMS) | 5000WX2 | 14000W |
| FrequencyResponse(+o/-0.3dB,1W/8Ω) | 20 Hz - 34 kHz | |
| THD 20 Hz - 20 kHz for 1 W | <0.1% | |
| Signal-to-Noise Ratio | >112 dBA | |
| Damping factor | >1000 | |
| Channel separation (Cross talk) at 1 kHz | >70 dB | |
| Input Connectors (per channel) | 3-pin XLR, electronically balanced | |
| Output Connectors (per channel) | Speakon or Binding Posts 2-pole | |
| Class circuitry | Class TD | |
| Tour Class Protection | ACL, IGM, Auto Ramp, short circuit, DC voltage, | |
| turn-on/off transient, current inrush, sub/ultrasonic input | ||
| Operating voltage, 230 V / 115 V normal | 150-260 V50/60Hz, / 70-140 V 50/60Hz selectable | |
| Voltage Gain(dB) | 23, 26, 29, 32, 35, 38, 41, 44 dB selectable | |
| Input impedance (unbalanced) | 20 k Ohm (10k Ohm) | |
| Level adjustment (per ch.) | Front-panel potentiometer, 31 position detente from -into 0 dB | |
| Dimensions (H×W×D) | 2U: 88×483×396mm | |
| Packing dimension | 180×560×500mm | |
| Net weight (kg) | 13 | 13 |
| Gross weight (kg) | 15 | 15 |
